Overview
In Oracle Solaris SRU45 released in May 2022, the Zones team delivered another major feature. This one is to allow for reconfiguring memory size of running Kernel Zones (KZs) on SPARC. Up until this SRU, we could only change the memory size of a Kernel Zone upon booting and/or rebooting it. If you had a long running KZ and you were getting out of memory, the only option possible was to increase the memory size in the zone’s configuration capped-memory resource, then rebooting the zone. We are very glad this is no longer the case on SPARC.
Note that this feature is about solaris-kz(7) branded zones only, also known as Kernel Zones. If you run native or S10 zones (i.e. solaris(7) or solaris10(7) branded zones), it works the other way around. There, one needs to explicitly limit zone memory caps in their configuration if you do not want them to consume as much as it is asked for. We will not discuss native nor solaris10 branded zones any further in this article.
For the feature to work, the guest Solaris system version is not relevant as long as it is at least 11.3 SRU8, released in 2016. That also means any Solaris 11.4 version is supported as the guest system. What is relevant is the host system version which must be 11.4 SRU45 or greater.
What about x86?
It is being worked on! The SPARC part was easier as its memory architecture is simpler than x86 and we wanted this feature to be useful for our SPARC customers even before x86 work is done. We hope to deliver the x86 part of the feature during this year (2022).
Update: the x86 part was integrated in our code base and is expected to be released with Oracle Solaris SRU51 in Nov 2022.
Enabling KZ memory live zone reconfiguration
To allow for changing KZ memory size on the fly, a new memory layout for a KZ guest must be used. For that reason, the KZ must be booted (rebooted) with this new memory layout. To notify the operating system the KZ is to use the new memory layout, one needs to add the memlzr modifier to the host-compatible zone configuration property. If you do not use the new memlzr modifier, the KZ will boot up fine, of course, but the memory live zone reconfiguration (LZR) feature will not be available for this zone. After configuring the host-compatible property, you need to reboot the KZ. Instead of the memlzr modifier, you can also use either the level2 or native levels as a value for host-compatible. Please see the solaris-kz(7) manual page for the details, in section Memory Live Zone Reconfiguration. For example:
# zonecfg -z somekz zonecfg:somekz> set host-compatible=level2 zonecfg:somekz> commit zonecfg:somekz> exit # zoneadm -z somekz reboot
Unfortunately, you cannot live migrate your running KZ to another target host, update your source host to SRU45, migrate the KZ back and increase its memory size on the fly. The KZ just must boot up with the new memory layout to support this feature. Note that from this SRU45 on, if you create a new KZ, the memlzr modifier will be put into the zone configuration by default as that is what is now in the default SYSsolaris-kz template. The templates reside in /etc/zones with all other zone configurations.
Configuring KZ memory live zone reconfiguration
The host-compatible settings mentioned above is the only requirement. However, you may also want to control the KZ guest page size. The page size here means the size of memory pages the guest address space consists of as seen by the hypervisor, and it has no relation to the page size the guest system itself can see from within.
You can either use what we have had since the KZ introduction, that is to set pagesize-policy property of the capped-memory resource to one of largest-only, largest-available, or smallest-only.
Since SRU45 however, you can also set pagesize-policy to fixed and then set the new property pagesize to one of allowable size. That is to better control the granularity of memory resizing. You can use anything greater or equal to 256M from the list of page sizes pagesize -a prints out on the host:
sparc-host# pagesize -a 8192 65536 4194304 268435456 2147483648 17179869184
In this case, we can use 256M, 2G, and 16G as possible values to pagesize.
As the guest address space consists of pages of specific size, you can only decrement or increment the KZ memory by the page size. If you create a KZ with 16G of memory and either set pagesize-policy to largest-only or use pagesize=16G, you will not be able to decrease the KZ memory requirements, and only increase it to 32G, 48G, 64G, and so on. For that reason, to test the feature, we recommend to use the fixed policy and set pagesize=256M.
Using KZ memory live zone reconfiguration feature
As with any other live zone reconfiguration, you either modify the permanent zone configuration, then apply it to the running zone, or you can directly modify the running configuration. Use whatever suites you. Note that if you use the latter and then you realize you want to keep the configuration change, you must manually modify the permanent zone configuration. In our examples, we directly modify the KZ running configuration via zonecfg -r.
Let’s start with a running KZ not supporting the feature yet. Enable the feature and set the guest page size to 256M:
root:sparc-host::~# zonecfg -z mykz zonecfg:mykz> set host-compatible=memlzr zonecfg:mykz> select capped-memory zonecfg:mykz:capped-memory> set pagesize-policy=fixed zonecfg:mykz:capped-memory> set pagesize=256M zonecfg:mykz:capped-memory> end zonecfg:mykz> commit zonecfg:mykz> exit
Now reboot the zone: zoneadm -z mykz reboot
After the KZ boots up, verify it has 8G of memory. We can see we have 1M of 8K sized pages (as mentioned before, this page size has nothing to do with the guest address space page size we configured above), meaning we have 8G of memory as expected.
root@mykz:~# pagesize
8192
root@mykz:~# kstat unix:0:system_pages:physmem
module: unix instance: 0
name: system_pages class: pages
physmem 1048576
Increasing the KZ memory size on the fly
Now let’s change directly the running configuration, to increase the KZ memory to 12G. Remember, this is done from within the host:
root:sparc-host::~# zonecfg -z mykz -r zonecfg:mykz> select capped-memory zonecfg:mykz:capped-memory> set physical=12G zonecfg:mykz:capped-memory> end zonecfg:mykz> commit Checking: Modifying capped-memory physical=12G Applying the changes zonecfg:mykz>
Now check the KZ itself:
root@mykz:~# kstat unix:0:system_pages:physmem
module: unix instance: 0
name: system_pages class: pages
physmem 1572864
root@mykz:~# bc
1572864 * 8 / 1024 / 1024
12
There is more ways to find out what is the memory size of a Solaris system instance, you could also do:
root@mykz:~# prtconf -v | grep ^Memory Memory size: 12288 Megabytes
Decreasing the KZ memory size on the fly
We can also decrease the memory the KZ is using, iff there is free memory to remove. In our case, we tried to go from 12G to 4G and as we can see, we could not go all the way down but by design the operation does not fail in such a case. The operation will remove as much as possible up to the required limit, and let you know the outcome in a warning message:
root:sparc-host::~# zonecfg -z mykz -r zonecfg:mykz> select capped-memory zonecfg:mykz:capped-memory> set physical=4G zonecfg:mykz:capped-memory> end zonecfg:mykz> commit Checking: Modifying capped-memory physical=4G Applying the changes warning: operation succeeded partially for capped memory (requested: 4G, final: 4.75G) zonecfg:mykz> root:sparc-host::~# zlogin mykz [Connected to zone 'mykz' pts/7] Last login: Mon Jun 20 14:15:46 2022 on kz/term Oracle Solaris 11.4.48.123.0 Assembled June 2022 root@mykz:~# prtconf -v | grep ^Memory Memory size: 4864 Megabytes
We can see above that going down to 4G was not possible but we removed almost all required memory and stopped at about 4.8G.
It does not mean the KZ will not have any free memory right now, only that we could not remove as many pages as possible, nor to move memory around to free more 256M sized pages. We can see the KZ still has enough free memory to operate for now, see the Free line below:
root@mykz:~# mdb -k Loading modules: [ unix genunix specfs dtrace zfs kcf rpcmod scsi_vhci zvblk zvmisc ldc mac ds sockfs ip hook neti dev arp random mdesc ksplice idm sas cpc fctl fcp fcip ptm smbsrv nfs ufs logindmux nsmb ] > ::memstat -v Usage Type/Subtype Pages Bytes %Tot %Tot/%Subt ---------------------------- ---------------- -------- ----- ----------- Kernel 182927 1.4g 29.3% Regular Kernel 144111 1.1g 23.1%/78.7% ZFS ARC Fragmentation 38816 303m 6.2%/21.2% ZFS 47438 371m 7.6% ZFS Metadata 5239 40.9m 0.8%/11.0% ZFS Data 8654 67.6m 1.3%/18.2% ZFS Data 8854 69.2m 1.4%/18.6% ZFS Data 10596 82.8m 1.7%/22.3% ZFS Data 7832 61.2m 1.2%/16.5% ZFS Kernel Data 6263 48.9m 1.0%/13.2% User/Anon 44810 350m 7.1% Exec and libs 1001 7.82m 0.1% Page Cache 5804 45.3m 0.9% Free (cachelist) 4890 38.2m 0.7% Free 335402 2.56g 53.8% Regular Free 330090 2.52g 53.0%/98.4% Physical pool reserved mem 5312 41.5m 0.8%/ 1.5% Total 622592 4.75g 100%
Live migration compatibility
Give that the KZ guests supporting the feature have the new memory layout, you can only live migrate those to hosts that also support the feature, that is those running SRU45+. If we try to live migrate our KZ to a host with an older Solaris system version, we fail when trying to import the KZ configuration.
root:sparc-host::~# zoneadm -z mykz migrate ssh://mem@hum.us.oracle.com zoneadm: zone 'mykz': Importing zone configuration on destination. zoneadm: zone 'mykz': configuration failed: -----BEGIN CONFIGURATION----- create -b set brand=solaris-kz set host-compatible=memlzr ... add capped-memory set physical=12G set pagesize-policy=fixed set pagesize=256M end ... -----END CONFIGURATION----- Error received from the target machine: On line 3: memlzr: Invalid argument
As expected, we do fail to migrate even if we do find an existing KZ configuration on the target host (which does not support the feature).
Conclusion
Being able to change the memory size of a running Kernel Zone was one of the most desired features we were being asked to deliver. The Zones team is very glad this has been implemented now, and we presently work on delivering the feature for x86 as well.
