Oracle SQL Developer & Data Modeler Support for Oracle Big Data SQL

Oracle SQL Developer and Data Modeler (version 4.0.3) now support Hive and Oracle Big Data SQL.  The tools allow you to connect to Hive, use the SQL Worksheet to query, create and alter Hive tables, and automatically generate Big Data SQL-enabled Oracle external tables that dynamically access data sources defined in the Hive metastore.

Let's take a look at what it takes to get started and then preview this new capability.

Setting up Connections to Hive

The first thing you need to do is set up a JDBC connection to Hive.  Follow these steps to set up the connection:

Download and Unzip JDBC Drivers

Cloudera provides high performance JDBC drivers that are required for connectivity:

  • Download the Hive Drivers from the Cloudera Downloads page to a local directory
  • Unzip the archive
    • unzip Cloudera_HiveJDBC_2.5.4.1006.zip
  • Two zip files are contained within the archive.  Unzip the JDBC4 archive to a target directory that is accessible to SQL Developer (e.g. /home/oracle/jdbc below):
    • unzip Cloudera_HiveJDBC4_2.5.4.1006.zip -d /home/oracle/jdbc/

Now that the JDBC drivers have been extracted, update SQL Developer to use the new drivers.

Update SQL Developer to use the Cloudera Hive JDBC Drivers

Update the preferences in SQL Developer to leverage the new drivers:

  • Start SQL Developer
  • Go to Tools -> Preferences
  • Navigate to Database -> Third Party JDBC Drivers
  • Add all of the jar files contained in the zip to the Third-party JDBC Driver Path.  It should look like the picture below:
    sql developer preferences

  • Restart SQL Developer

Create a Connection

Now that SQL Developer is configured to access Hive, let's create a connection to Hiveserver2.  Click the New Connection button in the SQL Developer toolbar.  You'll need to have an ID, password and the port where Hiveserver2 is running:

connect to hiveserver2

The example above is creating a connection called hive which connects to Hiveserver2 on localhost running on port 10000.  The Database field is optional; here we are specifying the default database.

Using the Hive Connection

The Hive connection is now treated like any other connection in SQL Developer.  The tables are organized into Hive databases; you can review the tables' data, properties, partitions, indexes, details and DDL:

sqldeveloper - view data in hive

And, you can use the SQL Worksheet to run custom queries, perform DDL operations - whatever is supported in Hive:

worksheet

Here, we've altered the definition of a hive table and then queried that table in the worksheet.

Create Big Data SQL-enabled Tables Using Oracle Data Modeler

Oracle Data Modeler automates the definition of Big Data SQL-enabled external tables.  Let's create a few tables using the metadata from the Hive Metastore.  Invoke the import wizard by selecting the File->Import->Data Modeler->Data Dictionary menu item.  You will see the same connections found in the SQL Developer connection navigator:

pick a connection

After selecting the hive connection and a database, select the tables to import:

pick tables to import

There could be any number of tables here - in our case we will select three tables to import.  After completing the import, the logical table definitions appear in our palette:

imported tables

You can update the logical table definitions - and in our case we will want to do so.  For example, the recommended column in Hive is defined as a string (i.e. there is no precision) - which the Data Modeler casts as a varchar2(4000).  We have domain knowledge and understand that this field is really much smaller - so we'll update it to the appropriate size:

update prop

Now that we're comfortable with the table definitions, let's generate the DDL and create the tables in Oracle Database 12c.  Use the Data Modeler DDL Preview to generate the DDL for those tables - and then apply the definitions in the Oracle Database SQL Worksheet:

preview ddl

Edit the Table Definitions

The SQL Developer table editor has been updated so that it now understands all of the properties that control Big Data SQL external table processing.  For example, edit table movieapp_log_json:

edit table props

You can update the source cluster for the data, how invalid records should be processed, how to map hive table columns to the corresponding Oracle table columns (if they don't match), and much more.

Query All Your Data

You now have full Oracle SQL access to data across the platform.  In our example, we can combine data from Hadoop with data in our Oracle Database.  The data in Hadoop can be in any format - Avro, json, XML, csv - if there is a SerDe that can parse the data - then Big Data SQL can access it!  Below, we're combining click data from the JSON-based movie application log with data in our Oracle Database tables to determine how the company's customers rate blockbuster movies:

compare to blockbuster movies

Looks like they don't think too highly of them! Of course - the ratings data is fictitious ;)
