Thursday Apr 04, 2013

Three Little Hive UDFs: Part 2

Introduction

In our ongoing exploration of Hive UDFs, we've covered the basic row-wise UDF.  Today we'll move to the UDTF, which generates multiple rows for every row processed.  This UDF built its house from sticks: it's slightly more complicated than the basic UDF and allows us an opportunity to explore how Hive functions manage type checking.

 We'll step through some of the more interesting pieces, but as before the full source is available on github here.

Extending GenericUDTF

 Our UDTF is going to produce pairwise combinations of elements in a comma-separated string.  So, for a string column "Apples, Bananas, Carrots" we'll produce three rows:



  • Apples, Bananas
  • Apples, Carrots
  • Bananas, Carrots



As with the UDF, the first few lines are a simple class extension with a decorator so that Hive can describe what the function does.

@Description(name = "pairwise", value = "_FUNC_(doc) - emits pairwise combinations of an input array")
public class PairwiseUDTF extends GenericUDTF {

private PrimitiveObjectInspector stringOI = null;

 We also create an object of PrimitiveObjectInspector, which we'll use to ensure that the input is a string.  Once this is done, we need to override methods for initialization, row processing, and cleanup.

@Override

  public StructObjectInspector initialize(ObjectInspector[] args) throws UDFArgumentException

{

    if (args.length != 1) {
      throw new UDFArgumentException("pairwise() takes exactly one argument");
    }

    if (args[0].getCategory() != ObjectInspector.Category.PRIMITIVE

        && ((PrimitiveObjectInspector) args[0]).getPrimitiveCategory() !=

PrimitiveObjectInspector.PrimitiveCategory.STRING) {

      throw new UDFArgumentException("pairwise() takes a string as a parameter");
    }


stringOI = (PrimitiveObjectInspector) args[0];

This UDTF is going to return an array of structs, so the initialize method needs to return aStructObjectInspector object.  Note that the arguments to the constructor come in as an array of ObjectInspector objects.  This allows us to handle arguments in a "normal" fashion but with the benefit of methods to broadly inspect type.  We only allow a single argument -- the string column to be processed -- so we check the length of the array and validate that the sole element is both a primitive and a string.

The second half of the initialize method is more interesting:

List<String> fieldNames = new ArrayList<String>(2);
    List<ObjectInspector> fieldOIs = new ArrayList<ObjectInspector>(2);
    fieldNames.add("memberA");
    fieldNames.add("memberB");
    fieldOIs.add(PrimitiveObjectInspectorFactory.javaStringObjectInspector);
    fieldOIs.add(PrimitiveObjectInspectorFactory.javaStringObjectInspector);
    return ObjectInspectorFactory.getStandardStructObjectInspector(fieldNames, fieldOIs);

}

Here we set up information about what the UDTF returns.  We need this in place before we start processing rows, otherwise Hive can't correctly build execution plans before submitting jobs to MapReduce.  The structures we're returning will be two strings per struct, which means we'll needObjectInspector objects for both the values and the names of the fields.  We create two lists, one of strings for the name, the other of ObjectInspector objects.  We pack them manually and then use a factor to get the StructObjectInspector which defines the actual return value.

Now we're ready to actually do some processing, so we override the process method.

@Override
  public void process(Object[] record) throws HiveException {
    final String document = (String) stringOI.getPrimitiveJavaObject(record[0]);

    if (document == null) {
      return;
    }
    String[] members = document.split(",");
java.util.Arrays.sort(members);
for (int i = 0; i < members.length - 1; i++)
for (int j = 1; j < members.length; j++)
if (!members[i].equals(members[j]))
forward(new Object[] {members[i],members[j]});

}

This is simple pairwise expansion, so the logic isn't anything more than a nested for-loop.  There are, though, some interesting things to note.  First, to actually get a string object to operate on, we have to use an ObjectInspector and some typecasting.  This allows us to bail out early if the column value is null.  Once we have the string, splitting, sorting, and looping is textbook stuff.

The last notable piece is that the process method does not return anything.  Instead, we callforward to emit our newly created structs.  From the context of those used to database internals, this follows the producer-consumer models of most RDBMs.  From the context of those used to MapReduce semantics, this is equivalent to calling write on the Context object.

@Override
  public void close() throws HiveException {
    // do nothing

}

If there were any cleanup to do, we'd take care of it here.  But this is simple emission, so our override doesn't need to do anything.

Using the UDTF

Once we've built our UDTF, we can access it via Hive by adding the jar and assigning it to a temporary function.  However, mixing the results of a UDTF with other columns from the base table requires that we use a LATERAL VIEW.

#Add the Jar
add jar /mnt/shared/market_basket_example/pairwise.jar;

#Create a function

CREATE temporary function pairwise AS 'com.oracle.hive.udtf.PairwiseUDTF';

# view the pairwise expansion output
SELECT m1, m2, COUNT(*) FROM market_basket

LATERAL VIEW pairwise(basket) pwise AS m1,m2 GROUP BY m1,m2;

[Read More]

Three Little Hive UDFs: Part 1

Introduction

In our ongoing series of posts explaining the in's and out's of Hive User Defined Functions, we're starting with the simplest case.  Of the three little UDFs, today's entry built a straw house: simple, easy to put together, but limited in applicability.  We'll walk through important parts of the code, but you can grab the whole source from github here.

Extending UDF

The first few lines of interest are very straightforward:

@Description(name = "moving_avg", value = "_FUNC_(x, n) - Returns the moving mean of a set of numbers over a window of n observations")
@UDFType(deterministic = false, stateful = true)

public class UDFSimpleMovingAverage extends UDF

We're extending the UDF class with some decoration.  The decoration is important for usability and functionality.  The description decorator allows us to give the Hive some information to show users about how to use our UDF and what it's method signature will be.  The UDFType decoration tells Hive what sort of behavior to expect from our function.

 A deterministic UDF will always return the same output given a particular input.  A square-root computing UDF will always return the same square root for 4, so we can say it is deterministic; a call to get the system time would not be.  The stateful annotation of the UDFType decoration is relatively new to Hive (e.g., CDH4 and above).  The stateful directive allows Hive to keep some static variables available across rows.  The simplest example of this is a "row-sequence," which maintains a static counter which increments with each row processed.

  Since square-root and row-counting aren't terribly interesting, we'll use the stateful annotation to build a simple moving average function.  We'll return to the notion of a moving average later when we build a UDAF, so as to compare the two approaches.

private DoubleWritable result = new DoubleWritable();
  private static ArrayDeque<Double> window;
  int windowSize;

  public UDFSimpleMovingAverage() {
    result.set(0);

}

 The above code is basic initialization.  We make a double in which to hold the result, but it needs to be of class DoubleWritable so that MapReduce can properly serialize the data.  We use a deque to hold our sliding window, and we need to keep track of the window's size.  Finally, we implement a constructor for the UDF class.

 public DoubleWritable evaluate(DoubleWritable v, IntWritable n) {
    double sum = 0.0;
    double moving_average;
    double residual;
    if (window == null)
    {
        window = new ArrayDeque<Double>();

}

Here's the meat of the class: the evaluate method.  This method will be called on each row by the map tasks.  For any given row, we can't say whether or not our sliding window exists, so we initialize it if it's null.

//slide the window
    if (window.size() == n.get())
        window.pop();

    window.addLast(new Double(v.get()));

    // compute the average
    for (Iterator<Double> i = window.iterator(); i.hasNext();)

sum += i.next().doubleValue();

Here we deal with the deque and compute the sum of the window's elements.  Deques are essentially double-ended queues, so they make excellent sliding windows.  If the window is full, we pop the oldest element and add the current value.

moving_average = sum/window.size();
    result.set(moving_average);

return result;

Computing the moving average without weighting is simply dividing the sum of our window by its size.  We then set that value in our Writable variable and return it.  The value is then emitted as part of the map task executing the UDF function.

Going Further

The stateful annotation made it simple for us to compute a moving average since we could keep the deque static.  However, how would we compute a moving average if there was no notion of state between Hadoop tasks? At the end of the series we'll examine a UDAF that does this, but the algorithm ends up being much different.  In the meantime, I challenge the reader to think about what sort of approach is needed to compute the window.

[Read More]
